Floodlight
Bahr
Bahr 1
Bahr 2
- Class I
- CB
- LM79
- LM80
- IP66
- Ta: +50°C
Operating and Electrical
- IEC protection class
- Class I
- Input voltage
- 100-305 VAC
- Mains frequency
- 50/60 Hz
- Power factor
- >0.90
- Wattage
- 500W / 600W
- Operating mode
- Inbuilt driver
- Control options
- Static / DALI
Photometry
- Light source
- LED module
- Color temperature
- 4000 K / 6500 K
- Color rendering index
- >70 Ra
- Lumens
- 75,000 lm / 90,000 lm
- Beam angle
- 30° / 45° / 60°
- LED life time
- >50,000hrs
Materials and Finish
- Body
- Die-cast aluminum
- Bracket
- Galvanized iron
- Diffuser
- Tempered glass
- Body finish
- RAL 9005
Installation and Application
- Installation
- Surface / Spigot
- IP Rating
- IP66
- IK Rating
- IK08
- Ambient temperature range
- 0 °C to +50 °C
Standard Variant
| Product | Watt | Lumen | Efficacy | CCT | Beam Angle | Control | |
|---|---|---|---|---|---|---|---|
| BHR1 | 500 | 75000 | 150 | 4000K | 30° | Static | |
| BHR1 | 600 | 90000 | 150 | 4000K | 30° | Static |
Ordering Code
Code:
- Class I
- CB
- LM79
- LM80
- IP66
- Ta: +50°C
Operating and Electrical
- IEC protection class
- Class I
- Input voltage
- 100-305 VAC
- Mains frequency
- 50/60 Hz
- Power factor
- >0.90
- Wattage
- 800W / 1,000W / 1,200W
- Operating mode
- Inbuilt driver
- Control options
- Static / DALI
Photometry
- Light source
- LED module
- Color temperature
- 4000 K / 6500 K
- Color rendering index
- >70 Ra
- Lumens
- 120,000 lm / 150,000 lm / 180,000 lm
- Beam angle
- 30° / 45° / 60°
- LED life time
- >50,000hrs
Materials and Finish
- Body
- Die-cast aluminum
- Bracket
- Galvanized iron
- Diffuser
- Tempered glass
- Body finish
- RAL 9005
Installation and Application
- Installation
- Surface / Spigot
- IP Rating
- IP66
- IK Rating
- IK08
- Ambient temperature range
- 0 °C to +50 °C
Standard Variant
| Product | Watt | Lumen | Efficacy | CCT | Beam Angle | Control | |
|---|---|---|---|---|---|---|---|
| BHR2 | 800 | 120000 | 150 | 4000K | 30° | Static | |
| BHR2 | 1000 | 150000 | 150 | 4000K | 30° | Static | |
| BHR2 | 1200 | 180000 | 150 | 4000K | 30° | Static |
Ordering Code
Code:
